东莞市研毅通电子科技有限公司，专注于工业主板、工控机、无风扇加固平板电脑、嵌入式无风扇工控机、无风扇车载计算机、AI边缘计算机、2.5 寸/3.5寸工业主板及板载内存、CPU ，SSD等产品的研发与销售。其产品以板载设计保障稳定性，工业主板具备宽温域（-40 - 85℃，）、高抗冲击性（通过 MIL - STD - 810G 标准，耐 50G 加速度冲击）及长 MTBF（10 万小时以上）等优势；无风扇工控机能适应极端环境，实现 24×7 稳定运行。产品广泛应用于5G+AI、边缘计算、物联网、工业 4.0、智能制造、工业自动化、测量测试、智能交通、智慧医疗、网络通信、汽车电子、智慧物流等领域。公司秉持专业、创新、服务理念，以专业团队把控品质、持续研发，提供全方位解决方案，助力各行业数字化、智能化发展。

INTRODUCTION

为了购买方能正确安装和以后的安全、可靠的运行，公司将提供相应的设备安装、调试、维护及使用的技术培训

技术服务

主板驱动下载

驱动下载

主板，工控机，平板电脑，扩展卡规格书下载

产品资料下载

技术支持

TECHNOLOGY

넳 넲

INDUSTRY APPLICATION

行业应用

热销产品

CI870CW

ntel® Core™ Ultra 7/5 Series processors, Q870 Chipset
2 x DDR5 SODIMM, Max 64GB
Multiple Independent display:
1 x HDMI®, 1 x DP, 1 x eDP / LVDS, 1 x Type C
5 x Intel 2.5 GbE LAN, 4 x USB 3.2 Gen 1, 4 x USB 2.0
1 x M.2 M Key, 2 x M.2 B Key, 1 x Nano SIM, 1 x PCIe x16
10 x COM, 8DI / 8DO, Audio
TPM 2.0, SMBus, I2C, I2S

2I110D

11th Gen Intel® Tiger Lake-UP3, i7 / i5 / i3 / Celeron CPU
1 x DDR4 SODIMM (Max. 32GB)
Multiple Independent display: HDMI, eDP
4 x Intel GbE LAN, 3 x USB 3.2 (type A), 6 x USB 2.0
2 x COM, 4DI / 4DO, 1 x Nano SIM
1 x M.2 B Key, 1 x M.2 M Key
TPM 2.0, SMBus

ARK-I+2I640PW + DM003 (Waterproof)

Intel® Elkhart Lake ATOM® x6413E / J6412 CPU
On Board LPDDR4 4 / 8GB
Independent display: VGA (M12)
M12 IO: 2 x Intel 2.5GbE , 4 x COM, 4 x USB 2.0, 1 x DC-Input,
Audio, SMBUS / I2C / SPI

NET-III 2I640CW

Elkhart Lake ATOM® X6413E / J6412 CPU CPU
On Board 4 / 8GB LPDDR4
Multiple Independent display: 2 x HDMI or DP
2 x Intel 2.5 GbE LAN, 2 x USB 3.0, 2 x USB 2.0, 4 x COM
1 x M.2, 1 x Nano SIM, 1 x Mini PCIe

HAWK - 3I130TW - M12

Intel® 13th Gen Raptor Lake-U, i7 / i5 / i3, Pentium CPU
Intel® 12th Gen Alder Lake-U, i7 / i5 / i3, Celeron CPU
Onboard LPDDR5, 16GB / 32GB
Multiple Independent display:
1 x HDMI, 1 x DP, 1 x Type C DP ALT Mode
5 x Intel 2.5 GbE LAN (M12), 3 x USB 3.2, 1 x USB 2.0
1 x M.2 M Key, 2 x M.2 BKey, 1 x Nano SIM
2 x COM, 4DI / 4DO, TPM 2.0, SMBus, I2C
ISO Wide Range DC-IN, CPC-Ignition on/off control

2I640HW

Intel® Elkhart Lake ATOM® x6413E / J6412 CPU
On Board LPDDR4 up to 8GB
Independent display: 1 x HDMI, 1 x LVDS, 1 x eDP
2 x Intel 2.5 GbE LAN, 1 x USB 3.0*, 5 x USB 2.0
1 x Mini PCIe, 1 x M.2, 1 x Nano SIM, 1 x PCIe x 2*
4 x COM, SMBus
Touch Screen, HD Audio, 4DI / 4DO
TPM 2.0

2I640DW

Intel® Elkhart Lake ATOM® x6413E / J6412 CPU
1 x DDR4 SODIMM socket, Max. 32GB
Independent display: 2 x HDMI (OEM to DP), 1 x eDP
3 x Intel 2.5 GbE LAN, 2 x USB 3.0, 3 x USB 2.0
2 x COM, 4DI / 4DO, 2 x M.2, 1 x Nano SIM
TPM 2.0, SMBus

2I640CW

Features
Intel® Elkhart Lake ATOM® x6413E / J6412 CPU
On Board LPDDR4 up to 8GB
Independent display: 2 x HDMI (DP), 1 x eDP
2 x Intel 2.5 GbE LAN, 2 x USB 3.0, 5 x USB 2.0
4 x COM, 1 x Mini PCIe, 1 x M.2, 1 x Nano SIM, SMBus
Touch Screen, 4DI / 4DO
TPM 2.0

3I610DW

6th / 7th Gen Intel® Skylake-U /
Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
2 x DDR4 SODIMM socket, Max. 64GB
Multiple Independent display: 2 x HDMI & eDP
5 x Intel GbE LAN, 4 x USB 3.0, 3 x USB 2.0, 4DI / 4DO
2 x COM, 2 x Mini PCIe, 1 x Nano SIM, LEX eIO, SMBus
TPM 2.0 (Optional)

3I610HW/BW

6th /7th Gen Intel® Skylake-U /
Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
2 x DDR4 SODIMM socket, Max. 64GB
Multiple Independent display: VGA, HDMI & LVDS
3 x Intel GbE LAN, 2 x USB 3.0, 4 x USB 2.0
6 x COM, 16DI / 16DO, 2 x Mini PCIe, 1 x SIM, SMBus
Battery Charger Function
TPM 2.0 (Optional)

2I612CW

6th / 7th Gen Intel® Skylake-U /
Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
1 x DDR4 SODIMM socket, Max up to 32GB
Multiple Independent display: 2 x HDMI (OEM to DP), eDP
2 x Intel GbE LAN, 4 x USB 3.0, 3 x USB 2.0, 2 x COM
2 x Mini PCIe, 4 DI / 4 DO, SMBus
TPM 2.0 (Optional)

2I610DW

6th / 7th Gen Intel® Skylake-U / Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
1 x DDR4 SODIMM socket, Max. 32GB
Independent display: VGA
3 x Intel GbE LAN, 3 x USB 3.0, 3 x USB 2.0
2 x COM, 4DI / 4DO, 2 x Mini PCIe, SMBus

2I610HW

6th / 7th Gen Intel® Skylake-U / Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
1 x DDR4 SODIMM socket, Max. 32GB
Multiple Independent display: VGA , HDMI & LVDS
2 x Intel GbE LAN, 2 x USB 3.0, 4 x USB 2.0, 1 x Micro USB 3.0 (OEM)
2 x COM, 4DI / 4DO, Touch Screen, 2 x Mini PCIe, SMBus

Twister CI370D

Intel® 8th / 9th Gen Coffee Lake-S i7 / i5 / i3 / Pentium / Celeron CPU
Intel® Q370 Chipset
2 x DDR4 SODIMM socket, Max. 64GB
Multiple Independent display: HDMI, DP
9 x Intel GbE LAN, 2 x SFP Fiber, 4 x USB 3.1, 2 x COM
1 x M.2 B Key, 2 x SIM, 2 x Mini PCIe,
1 x PCIe x 16 (PCIe x 16 + PCIe x 4 Signal)

2I385CW

ntel® Bay Trail-I Atom™ E3825 1.33GHz (Dual Core)
Intel® Bay Trail-I Atom™ E3845 1.91 GHz (Quad Core)
Intel® Bay Trail-D Celeron® J1900 2.0GHz (Quad Core)
On Board DDR3L 1066 / 1333 MHz 2GB / 4GB
Multiple Independent display: VGA & LVDS
2 x Intel GbE LAN, 4 x USB 2.0, Touch Screen
4 x COM, 4DI / 4DO, 2 x Mini PCIe, SMBus

2I385A

ntel® Bay Trail-I Atom™ E3825 1.33GHz (Dual Core)
Intel® Bay Trail-I Atom™ E3845 1.91 GHz (Quad Core)
Intel® Bay Trail-D Celeron® J1900 2.0GHz (Quad Core)
◼︎On Board DDR3L 1066 / 1333 MHz 2GB / 4GB
◼︎Independent display: VGA
◼︎2 x Intel GbE LAN, 4 x USB 2.0
◼︎4 x COM, 2 x Mini PCIe, SMBus

HAWK ORIN-TW (M12)

NVIDIA Jetson Orin™ Nano (Super): 4 / 8GB LPDDR5, 20 / 40 TOPs
NVIDIA Jetson Orin™ NX: 8 / 16GB LPDDR5, 70 / 100 TOPs
AI Accelerator: NVIDIA® Jetson Orin™ Nano (Super) / Orin™ NX
1 x DP, 5 x GbE (1 + 4 x Poe) (M12)
1 x USB 3.1 Type C ; 2 x USB 3.1 Type A ; 1x USB 2.0
2 x Isolated RS232 / RS422 / RS485, 1 x Isolated CANBus
1 x M.2 M key 4 x M.2 B key, 1 x M.2 E Key
Mic-in / Line-out ; 1 x Nano SIM
ISO Wide Range DC-IN, CPC-Ignition on/off delay control

3I810DW

8th Gen Intel® Whiskey Lake-U,
i7 / i5 / i3 / Pentium / Celeron CPU
2 x DDR4 SODIMM socket, Max. 64GB
Multiple Independent display: 2 x HDMI
5 x Intel GbE LAN, 4 x USB 3.1, 3 x USB 2.0
2 x COM, 8DI / 8DO, 1 x Mini PCIe,1 x Nano SIM
2 x M.2 B Key, Support NVME, SMBus
TPM 2.0 (Optional)

3I810HW

8th Gen Intel® Whiskey Lake-U,
i7 / i5 / i3 / Pentium / Celeron CPU
1 x DDR4 SODIMM (Max. 32GB) ; On board memory (OEM)
Multiple Independent display: VGA, HDMI, LVDS
3 x Intel GbE LAN, 3 x USB 3.0, 4 x USB 2.0
6 x COM, 16DI / 16DO, 1 x Mini PCIe, 1 x SIM, SMBus
1 x M.2 B Key, TPM 2.0 (Optional)
Battery Charger Function (3I810BW)

3I130TW

Intel® 13th Gen Raptor Lake-U i7 / i5 / i3, Pentium CPU
Onboard LPDDR5, 16GB / 32GB
Multiple Independent display:
1 x HDMI, 1 x DP, eDP, 1 x Type C DP ALT Mode
5 x Intel 2.5 GbE LAN, 3 x USB 3.2 ,
4 x USB 2.0, 1 x Type C
1 x M.2 M Key, 2 x M.2 B Key, 1 x Nano SIM
2 x COM, 4DI / 4DO, TPM 2.0, SMBus, I2C
ISO Wide Range DC-IN, CPC-Ignition on/off control

3I130DW

Intel® 13th Gen Raptor Lake-P/ Raptor Lake-U
Intel® 12th Gen Alder Lake-P / Alder Lake-U
i7 / i5 / i3 CPU
2 x DDR5 SODIMM (Max. 64GB)
Multiple Independent display: 2 x HDMI, eDP
5 x Intel 2.5 GbE LAN, 3 x USB 3.2, 5 x USB 2.0
1 x Mini PCIe, 1 x M.2 M Key, 1 x M.2 B Key, 1 x Nano SIM
2 x COM, 4DI / 4DO
TPM 2.0, SMBus, I2C

2I130DW

Intel® 13th Gen Raptor Lake-U ;
Intel® 12th Gen Alder Lake-U i7 / i5 / i3 CPU
1 x DDR5 SODIMM (Max. 32GB)
Multiple Independent display: HDMI®, eDP
4 x Intel 2.5 GbE LAN, 3 x USB 3.2 Gen 1 x 1 (type A), 4 x USB 2.0
2 x COM, 4DI/4DO, *2 x M.2, 1 x Nano SIM
TPM 2.0
Lab-tested and qualified by Intel® Edge Controls for Industrial (Intel® ECI) &
Time-Sensitive Networking (TSN)

Slim 10.4" PPC + 3I640CW

10.4" LCD with resistive touch screen
1 x DDR4 SODIMM, Max. 32GB
2 x 2.5GbE, 4 x COM, DVI, HDMI, 4 x USB, Audio
Wide Range 9~36V DC input
ABS front frame + Aluminum housing

HAWK-3I130DW

Intel® 13th Gen Raptor Lake-U/P , i7 / i5 / i3, Pentium CPU
Intel® 12th Gen Alder Lake-U/P, i7 / i5 / i3, Celeron CPU
2 x DDR5 SODIMM, Max 64GB
Multiple Independent display: 2 x HDMI (OEM to DP)
5 x Intel 2.5 GbE LAN, 3 x USB 3.2, 1 x USB 2.0, HD Audio
1 x M.2 M Key, 1 x M.2 BKey, 1 x Mini PCIe, 1 x Nano SIM
2 x COM, 4DI / 4DO, TPM 2.0, SMBus, I2C
Wide Range DC-IN

2I110AW

11th Gen Intel® Tiger Lake-UP3, i7 / i5 / i3 / Celeron CPU
1 x DDR4 SODIMM (Max. 32GB)
Multiple Independent display: 4 x HDMI
3 x Intel 2.5 GbE LAN, 2 x USB 3.2 (type A), 4 x USB 2.0
2 x COM, 4DI / 4DO, 1 x Nano SIM
1 x M.2 B Key, 1 x M.2 M Key
TPM 2.0, SMBus

2I130HW

Intel® 13th Gen Raptor Lake-P / U
Intel® 12th Gen Alder Lake-P / U i7 / i5 / i3 CPU
1 x DDR5 SODIMM (Max. 32GB)
Multiple Independent display: HDMI, eDP, LVDS
2 x Intel 2.5 GbE LAN, 4 x USB 3.2 Gen 1 x 1 (type A), 4 x USB 2.0
2 x COM, 4DI / 4DO, HD Audio
1 x Mini PCIe, 1 x M.2 B Key TPM 2.0
